Product highlights:
- 5-channel car amplifer
- 75 watts RMS x 4 + 180 watts RMS x 1 (at 4 ohms)
- 100 watts RMS x 4 + 300 watts RMS x 1 (at 2 ohms)
- 200 watts RMS x 2 bridged at 4 ohms + 300 watts RMS x 1 at 2 ohms
- channel 1 & 2: variable high-pass filter (50-5000 Hz, 12 dB/octave)
- channel 3 & 4: variable high- or band-pass filter (50-500 Hz, 12 dB/octave) — band-pass uses ch. 1/2 setting as its low-pass setting
- sub channel: low-pass (50-500 Hz, 12 or 24 dB/octave)
- optional wired remote controls sub or system level
- Class D amplifier design with NextD™ switching amp technology
- differential-balanced inputs eliminate noise coming from your vehicle's electrical system
- Advanced Rollback Protection System prevents thermal shut-down
Connection Features
- preamp and speaker-level inputs (speaker wire to RCA adapter required for speaker-level input)
- high-level inputs — up to 8 volts RMS (about 16 watts)
- DC offset or signal sensing auto turn-on eliminates need for remote lead
- 4-gauge power and ground leads and a 60-amp fuse recommended — wiring and hardware not included with amplifier
- no onboard fuses — when installing multiple amps in a system, an additional 60-amp in-line fuse between the distribution block and the amplifier is recommended
- 10-1/4"W x 2"H x 7-1/8"D
- warranty: 2 years
